PHASE MICRO Lite Test Cable Assemblies: Flexible, Durable Solutions for Everyday Test Environments
PHASE MICRO LITE Test Cable Assemblies: Reliable Performance for Routine Testing Applications
PHASE MICRO LITE Test Cable Assemblies: Reliable Performance for Routine Testing Applications Covering DC~50GHz, the PHASE MICRO LITE series delivers consistent electrical performance for production testing, quality control, and laboratory environments. Enhanced flexibility and visual identification features make this series a practical solution for high-throughput test applications where both performance and value matter.
Key Applications
Product Testing
High-volume manufacturing test environments requiring
consistent electrical performance and flexible cable routing.
Cost-effective solution for automated test equipment (ATE)
and production line validation.
consistent electrical performance and flexible cable routing.
Cost-effective solution for automated test equipment (ATE)
and production line validation.
Quality Control Labs
Routine component verification and acceptance testing.
Visual identification features (color-coded jackets)
simplify test setup and reduce measurement errors
in multi-channel configurations.
Visual identification features (color-coded jackets)
simplify test setup and reduce measurement errors
in multi-channel configurations.
Educational Institutions
Laboratory teaching environments and student training
programs. Durable construction withstands frequent handling
while maintaining measurement accuracy for RF fundamentals
and communication system courses.
programs. Durable construction withstands frequent handling
while maintaining measurement accuracy for RF fundamentals
and communication system courses.
R&D Prototyping
Early-stage development and proof-of-concept testing.
Flexible design accommodates iterative test configurations,
supporting rapid design cycles without sacrificing
measurement reliability.
Flexible design accommodates iterative test configurations,
supporting rapid design cycles without sacrificing
measurement reliability.
Field Service & Maintenance
On-site equipment commissioning and troubleshooting.
Compact, flexible form factor enables testing in
space-constrained installations and field deployment scenarios.
Compact, flexible form factor enables testing in
space-constrained installations and field deployment scenarios.
Power Handling
Efficient power management across diverse test scenarios:
- Average power: 50W (DC~18GHz)
- Peak power: 300W (pulse applications)
- Suitable for component-level testing and signal integrity validation
- Balanced thermal performance for extended test cycles
- Average power: 50W (DC~18GHz)
- Peak power: 300W (pulse applications)
- Suitable for component-level testing and signal integrity validation
- Balanced thermal performance for extended test cycles
Attenuation
Low-loss performance optimized for routine measurements:
- DC~6.5GHz: < 1.1 dB/meter (PLH06D)
- DC~26.5GHz: < 1.7 dB/meter (PLH21D)
- DC~40GHz: < 2.9 dB/meter (PLH16D)
- DC~50GHz: < 3.8 dB/meter (PLH13D)
Maintains signal integrity for accurate measurements
in production and laboratory test environments.
- DC~6.5GHz: < 1.1 dB/meter (PLH06D)
- DC~26.5GHz: < 1.7 dB/meter (PLH21D)
- DC~40GHz: < 2.9 dB/meter (PLH16D)
- DC~50GHz: < 3.8 dB/meter (PLH13D)
Maintains signal integrity for accurate measurements
in production and laboratory test environments.
Phase Change Versus Flexure
Phase Stability Performance
PHASE MICRO LITE maintains phase stability of ±5°
across flex cycles, suitable for routine testing applications
requiring consistent measurement repeatability.
PHASE MICRO LITE maintains phase stability of ±5°
across flex cycles, suitable for routine testing applications
requiring consistent measurement repeatability.
