Right from the dielectric core design & manufacturing
to complete coaxial cable assemblies, OSI is fully qualified for your test and measurement application.
OSI’s microwave cable assemblies and coaxial adapters can cover up to 50GHz.
With velocity of propagation up to 83%, OSI’s unique cable construction design will provide excellent electrical performance in lower attenuation,
phase and delay stability against environmental factors either in continuous flexures and temperature cycles.
A key factor, maintained electrical stability over time results
in more return in total cost of ownership, most of customers indicate.
EXCELLENCE
QUALIFIED
STABILITY
QUALITY
PHASE MICRO
PHASE MICRO
Learn more
TEST CORE
TEST CORE
Learn more
COAXIAL ADAPTER
COAXIAL ADAPTER
Learn more
| CABLE TYPE | 2.4mm(M) | 2.4mm(F) | 2.92mm(M) | 2.92mm(F) | 3.5mm(M) | 3.5mm(F) | SMA(M) | SMA(F) | N(M) | N(F) | |
|---|---|---|---|---|---|---|---|---|---|---|---|
| PHASE MICRO | P35 E13M (DC~50GHz) |
||||||||||
| P35 E14M (DC~40GHz) |
|||||||||||
| P35 E20M (DC~26.5GHz) |
|||||||||||
| TEST CORE | TC LH13D (DC~50GHz) |
||||||||||
| TC E14 (DC~40GHz) |
|||||||||||
| TC E16 (DC~40GHz) |
|||||||||||
| TC E21 (DC~26.5GHz) |
|||||||||||
| TC E31 (DC~18GHz) |
|||||||||||
| TC E18 (DC~8.5GHz) |
|||||||||||
